Brookfield Engineering Labs., Inc. Page 10 Manual No. M/97-164-F1102
II. GETTING STARTED
II.1 Autozero
Before readings may be taken, the Viscometer must be Autozeroed. This action is performed each
time the power switch is turned on. The display window on the Viscometer will guide you through
the procedure as follows:
Turn the power switch (located on the rear panel) to the ON position. This will result in the screen
display shown in Figure 3. The viscosity measurement range is indicated by the information in the
lower left, in this case RV. For most DV-II+ Viscometers, this information will be either “LV” or
“RV”.
BROOKFIELD DV-2+
RV VISCOMETER
Figure 3
After a few seconds, the following screen appears:
BROOKFIELD DV-2+
VERSION: 6.1
Figure 4
No key press is required at this point. After a short time, the display will clear and the following
will be displayed:
REMOVE SPINDLE
PRESS ANY KEY
Figure 5
After removing the spindle and pressing any key, the DV-II + begins its Autozero. The screen will
flash "Autozeroing."
After approximately 15 seconds, the display shows the screen in Figure 6:
REPLACE SPINDLE
PRESS ANY KEY
Figure 6
Pressing any key at this point results in the display of the DV-II + default screen:
CP 0.0 20.1C
OFFRPM % 0.0
Figure 7
The display will vary depending upon the selection of temperature (
°
F or
°
C) and units of viscosity
(cP or mPa•s).
