DB25 Pinout
Breakout cables for DB25‑to‑XLR AES3 digital connections are readily
available. To create a custom cable for the 6416dio digital I/O connections,
use the following table and diagram. Be sure to use the wiring pinout that
matches the pinout for the device to which the 6416dio will be connected.
DB25
Pin
Yamaha
Compatible
DB25
Pin
Tascam/Digidesign
Compatible
1
Digital In 1/2 +
1
Digital Out 7/8 +
2
Digital In 3/4 +
2
Ground
3
Digital In 5/6 +
3
Digital Out 5/6 ‑
4
Digital In 7/8 +
4
Digital Out 3/4 +
5
Digital Out 1/2 +
5
Ground
6
Digital Out 3/4 +
6
Digital Out 1/2 ‑
7
Digital Out 5/6 +
7
Digital In 7/8 +
8
Digital Out 7/8 +
8
Ground
9
No Connect
9
Digital In 5/6 ‑
10
Ground
10
Digital In 3/4 +
11
No Connect
11
Ground
12
Ground
12
Digital In 1/2 ‑
13
Ground
13
No Connect
14
Digital In 1/2 ‑
14
Digital Out 7/8 ‑
15
Digital In 3/4 ‑
15
Digital Out 5/6 +
16
Digital In 5/6 ‑
16
Ground
17
Digital In 7/8 ‑
17
Digital Out 3/4 ‑
18
Digital Out 1/2 ‑
18
Digital Out 1/2 +
19
Digital Out 3/4 ‑
19
Ground
20
Digital Out 5/6 ‑
20
Digital In 7/8 ‑
21
Digital Out 7/8 ‑
21
Digital In 5/6 +
22
Ground
22
Ground
23
Ground
23
Digital In 3/4 ‑
24
Ground
24
Digital In 1/2 +
25
Ground
25
Ground
