Controls and Connection Sockets

RFOUT
To connect to the aerial terminal on a TV set.

© NORMAUS-VIDEO OUT/TEST SIGNAL

NORMAL: Normally set to this position.
S-VIDEOOUT (AV1):

Set to this position when connecting the
VTR to a TV set equipped with 21 -pin

Euro-AV Connector with pins tor separate
Y/C signal input.

TEST SIGNAL:

Set to this position when tuning the TV into
the VTR.
The test signal is transmitted on channel
36 and AVI.

® AUDIO OUT

To connect the sound to a stereo audio system.

© RFIN

To connect to the external aerial.

@ CHADJ.

To adjust the RF transmitting channel 32-40.

® AVI

This 21 -pin scart terminal carries input and output
signals for both picture and sound. TV sets equipped
with a similar socket can be connected here.
This is also called Scart

Perite!
Euro Connector
Euro AV

1 3 5 7 9 11 t3 15 17 1Э

--------------------------------------------------------------------------------------

0000<Х>0<К>00\г'

■5 000 000 000 \

2 А 6 Э 10 12 14 16 18 20

NORMAL (AV1/AV2)

S-VIDEO (AVI)

1 AUDIO OUTPUT

CH2(R)

CH2 (R)

2 AUDIO INPUT CH2(R) 2 AUDIO INPUT CH2{R)

3 AUDIO OUTPUT

3 AUDIO OUTPUT CHI

CHI (L)

(L)

4 AUDIO GND

5 BLUE GND

5 No connection

6 AUDIO INPUT CHI (L) 6 AUDIO INPUT CH1 (L)
7 BLUE

7 No connection

8 SWITCHING

VOLTAGE

9 GREEN GND

9 No connection

10 No connection

11 GREEN

11 No connection

12 No connection

13 RED GND

13 No connection

14 BLANKING GND

14 No connection

15 RED

15 COUT

16 BLANKING

16 No connection

17 VIDEO OUTPUT GND17 VIDEO OUTPUT GND
18 VIDEO INPUT GND

18 No connection

19 VIDEO OUTPUT

19 YOUT

20 VIDEO INPUT

21 GND

Caution: RGB reservation for only E/E operation when

connecting the Pay TV decoder

AV2
To connect to a decoder or another VTR.

•Only used as the input socket.

VIDEO OUT
To connect the video cable to a TV or another VTR.

S-VIDEO OUT
To connect the S-Video cable to a TV or another VTR
that has a S-Video input socket.

AC IN

TO connect to the main power supply.
