(T) Infrared Remote Control Receiver Window
Cg) OPERATE Indicator
Lights up when the VTR is turned on.
(3) STAND BY Indicator
Lights up when the AC mains lead is connected and
the VTR is turned off.
@ TIMER REC Indicator
Lights up when the timer recording function is on.
TAPE IN Indicator
Lights up when a cassette is inserted.
eg)
S-VIDEO IN (AV3)
To connect the S-Video cable to a movie camera or to
another VTR that has a S-Video output socket.
@ VIDEO IN (AV3)
To connect the video cable to a movie camera or to
another VTR.
(8) AUDIO IN (AV3)
To connect the audio cable to a movie camera or to
another VTR.
CD EDIT
To connect a movie camera or another VTR equipped
with an edit socket or an editing controller.
® SYNC. EDIT
To connect a movie camera or another VTR equipped
with synchronized editing capability.
® MIC
To connect a microphone for recording. Once
connected, this socket has priority.
® PHONES
To connect stereo headphones.
