Customizing this unit (MANUAL SETUP)
■ Speaker distance OSP DIST h NCE
Use this feature to manually adjust the distance of each
speaker and the delay applied to the respective channel.
Ideally, each speaker should be the same distance from the
main listening position. However, this is not possible in
most home situations. Thus, a certain amount of delay
must be applied to the sound from each speaker so that all
sounds will arrive at the listening position at the same
time.
OSP DISTANCE 1/2
^ UNIT---
FRiDNT L- ■■10.0ft
FRONT R- ■■10.0ft
CENTER-■
SUR. L--
SUR. R-- ■■■8.0ft
[ A ] / [ T ] ; iJp/Doun
[ - H 1 / C N - ] ; Select
OSP DISTANCE 2/2
^ SBL....... ■8.0ft
SBR...... ■8.0ft
SUFR..... ■10.0ft
PRNS L--- ■10.0ft
PRNS R--- ■ 10.0ft
[ A ] / [ T ] ; IJp/Down
[■^]/[^]: Adjust
Unit for the speaker distance adjustment UN IT
Initial setting:
[U.S.A. and Canada models]: feet (ft)
[Other models]: meters (m)
Chok»!
meters (m) Adjusts speaker distances in meters.
feet (ft) Adjusts speaker distances in feet.
Speaker distances
Control range: 0.30 to 24.00 m (1.0 to 80.0 ft)
Control step: 0.10 m (0.5 ft)
Initial setting:
FRONT L/FRONT R/SWFR/PRNS L/
PRNS R: 3.00 m (10.0 ft)
CENTER: 2.60 m (8.5 ft)
SUR. L/SUR. R/SBL/SBR: 2.40 m (8.0 ft)
' . ' ' -|
FRONT L Front left speaker
FRONT R Front right speaker
CENTER Center speaker
SUR.L Surround left speaker
SUR.R Surround right speaker
SBL Surround back left speaker
SBR Surround back right speaker
SWFR Subwoofer
PRNSL Presence left speaker
PRNSR Presence right speaker
Notes
• The available speaker channels differ depending on the setting
of the speakers.
• Instead of “SBL” and “SBR”, “SUR.B” is displayed if “SUR.B
L/R SP” is set to either “SMLxl” or “LRGxl” (see page 86).
■ Test tone D>TEST TONE
Turns the test tone output on or off for the “SPEAKER
SET’, “SP LEVEL”, and “SP DISTANCE” settings.
D)TE5T ТОНЕ
>iDFF iDN
С-и]/[^]: Select
[ENTER]: Return
Chokm
'L ' ''' '’J
OFF This unit does not output the test tone for the
“SPEAKER SET’, “SP LEVEL”, and “SP
DISTANCE” settings.
ON This unit outputs the test tone for the
“SPEAKER SET’, “SP LEVEL”, and
DISTANCE” settings.
"SP
If you use a handheld sound pressure level meter, hold at arm’s
length and point upwards so that the meter is in the listening
position. With the meter set to the 70 dB scale and to C SLOW,
calibrate each speaker to 75 dB.
.№>11* ■
This function is automatically turned off if you exit from “BASIC
MENU’’.
