Appendix
Cable
Paraiiei IrDA
IEEE 1284 RS-232C
Serial
RS-232C
LocalTalk (RS-422)
IrDA
Bi-directional parallel interface
The bi-directional parallel interface is based on the IEEE P1284-B standard.
If your computer has a bi-directional parallel port, the printer driver and printer can take
advantage of the fastest possible data transfer.
Specifications:
Connector type 57-30360 (AMPHENOL) or equivalent
cable use a shielded cable 2 meters (6.6 feet) or less in length
Pin configuration
Signal pin
Return side
pin
Signal Signal pin
Return side
pin
Signal
1 19 n Strobe 13 28 Select
2 20 Data 1 14 30 nAutoFd
3 21 Data 2 15
4 22 Data 3 16 SG
5 23 Data 4 17 FG
6 24 Data 5 18 +5V
7 25 Data 6 31 30 ninit
8 26 Data 7 32 29 nFault
9 27 Data 8 33 SG
10 28 nAck 34
11 29 Busy 35 -(■5V
12 28 PError 36 30 nSelectin
