Setting up the Printer
Loading media
For detailed information about media, see page 60.
Loading paper in the 1st cassette
The 1st cassette can hold up to 500 sheets of paper.
Media Description
Laser paper
One-sided printing: 60 to 90 g/m^ (16 to 24 lbs.)
Duplex printing: 75 to 90 g/m^ (20 to 24 lbs.)
N ote
• The directions for loading paper in the OPT cassette of 2nd feeder differ from these
directions.
у Pull the cassette completely out of the printer.
2
To load the paper of the Legal or Folio (24 lbs., 90 size into
the cassette, push down the green lever on the left side of the
cassette to lock it into the small hole under the slot.
Cassette
Green lever
N otes
• If the cassette is not properly adjusted, the printer might display an error
message or paper might jam,
• To reset the green lever,
a) Lift the green lever.
b) Release it into the slot.
Green lever
