Care and Maintenance
a)
Position the toner cartridge as shown with the arrow on the toner
cartridge pointing to the back of the printer. Slide the toner
cartridge into the printer as far as it will go.
b)
Push the toner cartridge to set it properly as shown below.
g
Close the top cover.
The paper jam message should be cleared.
PAPER JAM 2’
y Open and close the top cover.
The paper comes out of the printer and the paper jam message is cleared.
If the paper jam message is not cleared, follow the next steps.
Open the rear cover.
Fuser cover
[Fuser is behind the fuser cover.]
C
aution
• The fuser cover and fuser are hot.
—Take care when clearing the jammed paper.
—If you need to open the fuser cover, turn off the printer and wait 10 minutes
{after opening the rear cover) for the fuser to cool before opening the fuser
cover.
53
