Installing Ribbon Cassette
-f O Turn the power on.
O Open the smoked plastic cover.
Move the head gap lever to position
“
6
”.
Install the ribbon cassette and push
down 4 arrows until they click into
place.
Note:
• Do not take off the blue ribbon guide from
the ribbon.
O Lift the blue ribbon guide from the
ribbon cassette.
@ Slide the blue ribbon guide
between the printhead nose and
the ribbon mask, and push it
down.
Note:
• If the ribbon does not insert easily between
the printhead nose and the ribbon mask,
rotate the knob on the ribbon cassette to
reduce the slack.
Make sure the ribbon is not twisted and
rotate the knob to remove any slack.
0
Close the smoked plastic cover.
Y Adjust the head gap lever for the
thickness of paper you are using.
□
Position Used for
1 or 2 Thinner sheets
3, 4,5 or 6 Thick sheets or
multi-part forms
