LabPro Technical Manual 75
Analog Inputs (Cont.)
DC Parameters
Integral Nonlinearity +/- 0.5 LSB
Differential Nonlinearity +/- 1 LSB (no missing codes)
Offset Error 1 LSB
System noise +/- 1 LSB
AC Parameters
Input Bandwidth: 0-5V input 50kHz (f3dB)
Input Bandwidth: +/-10V input 5kHz (f3dB)
* For the Ch4 +/-5V input, use the +/- 10V input AC and DC parameters.
Analog Output
Connector CH4 same pin as Vin (+/- input)
Signal Output Range +/- 2V at 100mA
Configuration 2 – 12 bit DACs (amplitude and offset)
Current sense resistor 0.1
Ω
1%
Update rate 200 Hz
Max load 8
Ω
Protection Short circuit to ground
Digital I/O
Connector British Telcom Left Hand connector
Signals 8 configurable I/O lines; 4 on each channel
Input Characteristics:
Input High Voltage
Input Low Voltage
3.5V min.
1.5V max.
Output Characteristics:
Output High Voltage
Output Low Voltage
4.2V min. Ioh = -400uA
0.45V max. Iol = 1.6mA
Timing Resolution 1.6
µ
s, 100
µ
s (depending on mode).
