Page 2
Installation Guidelines
W A T E R W O R K S
Waterworks is a registered trademark of Waterworks Inc.
.25 Wall Mounted Tub Spout
PARTS TABLE
ITEM NO. DESCRIPTION
QTY.
These guidelines have been prepared for the professional contractor to aid in the installation of:
.25 WALL MOUNTED TUB SPOUT (PTTU82) All dimensions are based on origin specification
and are subject to change and variation. Please consult your Design Associate for current specifications.
1
1
1
SPOUT ADAPTER
2
1
ESCUTCHEON GASKET
3
1
ESCUTCHEON
4
1
WASHER
5
1
SPOUT
6
1
AERATOR
1
7
AERATOR TOOL
2
3
4
5
6
7
04.11.07
