Page 2
Installation Guidelines
W A T E R W O R K S
Waterworks is a registered trademark of Waterworks Inc.
1
1a
2
3
3a
3b
3c
3d
4a
4
PARTS TABLE
ITEM NO. DESCRIPTION
QTY.
3d
4c
4b
5
5a
5b
7c
7b
7a
7
8
5c
5e
5g
5d
5f
5h
6
5
6a
6b
6d
6c
1
1
ESCUTCHEON
1a
O-RING, INNER
2
ELBOW,
1
2
" NPT
3
CHECK VALVE
3a
WASHER
3b
CHECK VALVE HOUSING
3c
FLOW RESTRICTOR, 2.5 GPM
3d
WASHER, RUBBER-
1
2
"
4a
NUT
4b
NUT, CONICAL
4c
O-RING, OUTER
5
NUT, HEIGHT ADJUSTMENT
5a
WASHER
5b
THREADED SHAFT
5c
SLEEVE
5d
POSITIONING ASSEMBLY
5e
SPRING
5f
WASHER
5g
BALL
5h
NUT, ANGLE ADJUSTMENT
6
HANDSHOWER INLET BASE
6a
HANDLE
6b
6c
6d
7
7a
7b
7c
2
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
HOSE
HANDSHOWER INLET PIPE
O-RING
HANDSHOWER HEAD
INDICE
SCREW
BAR END
ANCHOR
Julia Handshower on Bar
These guidelines have been prepared for the professional contractor to aid in the installation of:
JULIA HANDSHOWER ON BAR (JUHS01-K, JUHS02-K, JUHS03-K) All dimensions are
based on original specification and are subject to change and variation. Please consult your Design
Associate for current specifications.
1
8
Bar
3c 2.5 GPM FLOW RESTRICTOR
10.06.06
