Page 2
Installation Guidelines
W A T E R W O R K S
Waterworks is a registered trademark of Waterworks Inc.
.25 Handshower On Hook
These guidelines have been prepared for the professional contractor to aid in the installation of:
.25 HANDSHOWER ON HOOK (PTHS25) All dimensions are based on origin specification and are
subject to change and variation. Please consult your Design Associate for current specifications.
PARTS TABLE
ITEM NO. DESCRIPTION
QTY.
6
1
1
ADAPTER
1
2
3
4
5
7
8
9
10
8
2
1
GASKET
3
1
ESCUTCHEON
4
1
WASHER
5
1
ELBOW
6
1
HANDSHOWER
7
1
FLOW RESTRICTOR/
CHECK VALVE
8
1
HOSE
9
1
HOOK
10
1
CHECK VALVE
04.11.07
