EASTON CLASSIC
Exposed Thermostatic System with 8" Shower Rose
Installation Guidelines
Page 2 of 5
Rev - 01
12.6.2012
These guidelines have been prepared for the professional contractor to aid in the installation of:
EASTON CLASSIC EXPOSED THERMOSTATIC SYSTEM WITH 8' SHOWER ROSE (STYLE No. EAXS32) &.
EASTON HANDSHOWER WITH DIVERTER (STYLE No. EAHS32.
All dimensions are based on original specification and are subject to change and variation.
Please consult your Design Associate for current specifications.
9. With the valve mounting plate against the wall, mark
its location so the plate can be secured.
10. Loosen the compression nuts and pull the valve body
assembly off of the supplies.
11.
Loosen the 2.5 mm hex screw (39) on the valve
mounting plate (41).
12. Hold the plate against the wall in its proper location
based on the marks made in step 9 while making sure
the screw holes are located at 9 and 3 o'-clock and
then make a mark for each of the 2 holes.
13. Drill 2 holes at the proper location and secure the
mounting plate to the wall using the mounting
hardware (40,42) provided.
14. Align the valve body with the supplies and mounting
plate and then attach the valve body assembly to the
mounting plate by tightening the 2.5 mm hex screw
(39).
15. Complete final connections by tightening the
compression nuts (34).
IF A HAND SHOWER WILL BE INSTALLED, CONTINUE
WITH STEP 16; IF NOT, CONTINUE WITH STEPS 18-21:
16. With the hand shower hose connection pointing to
the right, determine the proper position of the
diverter. For comfortable operation of the levers
(3,20d), there should be a minimum 4" gap between
the diverter handle positioned at 6 o'clock and the
valve handle positioned at 12 o'clock as shown in the
illustration.
17. Cut a piece off of the riser to make the connection
between the valve and diverter. Make sure this piece
is long enough to be inserted deep enough into the
valve and diverter to assure a tight connection. Install
the diverter.
18. Determine the ideal height of the riser and proper
location of the 2 riser supports as shown in the
drawing. The riser can be cut as needed.
19. Remove the 1.5mm set screw from each riser support
and then secure the riser mounting plates to the wall
using the hardware provided.
20. Lightly lubricate the o-ring inside each riser support,
slide the supports onto the riser, then insert the riser
into the valve body or diverter body as applicable.
21. Secure the riser supports to the riser mounting plates
and then tighten ALL connections. If a hand shower is
NOT being used, continue with “Calibrate the
Temperature”.
22. Thread the check valve housing (23h) onto the
diverter elbow (8d) making sure a 1/2" washer (22h)
is installed at the connection. Make sure the check
valve is inside the housing.
23. Using a 2mm hex wrench (17ah), loosen the 2mm set
screw (17h) and remove the mounting plate (12h) from
the hand shower hook (14-18h).
24. Determine the ideal location of the hook and then drill
2 holes to accommodate the mounting hardware
provided.
25. Position the mounting plate (12h) with the flat side
facing the wall and then secure it using the 2 anchors
(11h) and screws (13h) provided.
26. Position the hook against the mounting plate while
making sure the 2mm set screw is located at 6 o'clock
as shown and then tighten the set screw. The opening
of the hook MUST face to the left so the tapered end
of the hose fits properly.
27. Thread the knurled end of the hose (25h) onto the
check valve housing and then thread the conical end
onto the hand shower (1-9h) making sure a 1/2"
washer (10h,24h) is included at both connection
points.
28. Rotational adjustment of the hook can be made by
removing the hook and turning the 5mm hex bolt
(14h) on the back side of the hook.
CALIBRATE THE TEMPERATURE:
¾ The risk of scalding exists until the installer has
properly calibrated the temperature setting.
29. Unthread the handle assembly (1-6) from the handle
base (11) and then insert a screw driver tip into the
hole on the side of the handle base and pop off the
handle cap (7,8). Remove the handle screw (9).
30. Fully open the valve to HOT by rotating the handle
base counter clockwise. When rotated counter
clockwise, the valve sequence is: OFF-COLD-HOT.
31. With the valve all the way open, set the upper
temperature limit by inserting a 2.5mm hex wrench
into the valve stem (20) and rotate it counter
clockwise to increase the temperature and clockwise
to decrease the temperature.
32. Turn the valve off and then on again to verify the
temperature range; adjust as needed.
33. Reinstall the handle while making sure the o-ring (10)
is included.
COMPLETE FINAL INSPECTION:
34. Install the showerhead onto the riser. Note there is a
2.5gpm flow restrictor in the swivel.
35. If desired, a bead of caulk or silicone may be applied
where the escutcheons contact the wall.
36. Operate the valve and make sure the diverter is
operating properly.
¾ If further assistance is required, please contact Product
Support at 1-800-927-2120 (8am-6pm EST).
