Kit components service parts index – Waterworks Henry Thermostatic Control Valve Trim User Manual
Page 9
7
W W W.WATERWORKS.COM
6
PRODUCT SUPPORT: 1 (800) 927-2120 (EXT 2)
*FINISH/COLOR MUST BE SPECIFIED WHEN ORDERING
++SUPPLIED AS A PAIR
STYLES: HNTH01, HNTH10
KIT COMPONENTS
SERVICE PARTS INDEX
DOCUMENT: SPHN06_REV01
812191
TRIM CONNECTOR
ALL THREAD TUBE
SQUARE TUBE
STYLE
DESCRIPTION
PG
103761*
C ROS S H A N DL E
3
103759*
FAC E PL AT E T R I M
4
103746
FA S T E N I NG SE T S C R E W
5
103762*
L E V E R H A N DL E
3
103760*
L I M I T S T OP
5
81 2191
T R I M CON N EC T OR
6
594565
T R I M N U T
2
