Page 3
Installation Guidelines
W A T E R W O R K S
Waterworks is a registered trademark of Waterworks Inc.
.25 Thermostatic Shower Valve Trim
8
7
6
5
4
3
2
1
04.30.07
PART and SERVICE PACK TABLE
NON-SERVICEABLE
DESCRIPTION
QUANITY.
1
2
TRIM COVER
1
HANDLE
1
5
6
O-RING
TRIM PLATE
1
1
PTPSV02
DESCRIPTION
3
SET SCREWS
3
WWPMS00
DESCRIPTION
1
WWPMS04
ITEM. DESCRIPTION
4
TRIM NUT
7
8
SQUARE TUBE
THREADED SLEEVE
1
1
PART
PACK
ITEM.
ITEM.
ITEM.
QUANITY.
QUANITY.
QUANITY.
N/A
N/A
N/A
N/A
1
3
1
1
These guidelines have been prepared for the professional contractor to aid in the installation of:
.25 THERMOSTATIC SHOWER VALVE TRIM (PTSV58 & GUSV78R) All dimensions are
based on original specification and are subject to change and variation. Please consult your Design Associate
for current specifications.
