Installation Guidelines
W A T E R W O R K S
Waterworks is a registered trademark of Waterworks Inc.
These guidelines have been prepared for the professional contractor to aid in the installation of:
JULIA FOUR HOLE KITCHEN MIXER WITH SPRAY, CROSS HANDLES (JUKM18) &
LEVER HANDLES (JUKM19-K, JUKM20-K, JUKM21-K)All dimensions are based on original
specification and are subject to change and variation. Please consult your Design Associate for current
specifications.
Julia Four Hole Kitchen Mixer With Spray
15. Reinstall the tee/diverter assembly then connect
each of the supply hoses to the adjacent side valve
making sure they are not pinched/kinked.
RINSE INSTALLATION
16. Remove the rinse return attachment hardware
(43a(1) - 43c) from the return shank (43)
17. Insert the return assembly (10, 43a(1), 43)
through the hole of the mounting surface.
18. Place 1 rubber gasket (43a) then spout washer
(43b) and nut (43c) onto the return shank (43).
19. Tighten the nut to secure the return to the
mounting surface.
20. Insert the hose and rinse assembly (39-42,
44-44b) into the rinse return.
21. Install a washer (44c) into the hose end then
thread the hose onto the tee (35).
22. Connect the side valves (15) to the water supply
valves (not supplied).
INSPECT THE INSTALLATION
23. Unscrew and remove the aerator assembly
(36-37) which includes a flow restrictor.
24. Carefully open the hot and cold valves to flush out
any debris in the supply lines.
25. Operate the rinse by pressing the thumb lever. If
the rinse does not shut off completely, remove
the nut on the face of the rinse. Rotate the
slotted screw left or right then operate the thumb
lever to verify adjustment. Repeat as needed.
26. Inspect all connections for leaks.
27. Close the valves and reinstall the aerator assembly.
If further assistance is required, please contact Product
Support at 1-800-927-2120 (8am-7pm EST)
10.06.06
