background image


RW ATLAS

Low Profile Three Hole Deck Mounted Lavatory

Faucet

INSTALLATION GUIDELINES

Page 4 of 4


6.26.2012

These guidelines have been prepared for the professional contractor to aid in the installation of:
RW ATLAS LOW PROFILE THREE HOLE LAVATORY FAUCET WITH METAL WHEEL HANDLES
(STYLE# RWLS20) & METAL LEVER HANDLES (STYLE # RWLS30)
All dimensions are based on original specification and are subject to change and variation.
Please consult your Design Associate for current specifications.

Description

QTY

HGLS01

(CROSS HANDLE)

1 Cross

Handle

2

10

Valve Body,
Clockwise Close

2

HGLS10

(LEVER HANDLE)

2 Lever

Handle

2

10

Valve Body,
Clockwise Close

1

24

Valve Body, Counter-
clockwise Close

1

COMMON PARTS

3 Escutcheon

2

4 Foam

Gasket

2

5 Retaining

Collar

2

6

Retaining Collar O-
Ring

2

7 Rubber

Washer

3

8 Metal

Washer

3

9 Nut

3

11

Inlet Supply Nut

2

12

Lift Knob & Rod

1

13 Spout

Assembly

1

14 Rubber

Gasket

1

15 Rubber

Washer

1

16

Flow Restrictor Cap

1

17 Flow

Restrictor

1

18

Flexible Supply Hose

2

19 Strainer

Washer

1

20 Inlet

Tee

1

21 O-Ring

1

22 Spacer

1

23 Packing

Nut

1

25 Screw

1

26

Rod Connecting Link

1

27 Retaining

V-Clip

1

28 Nut

1

29

Horizontal Pivot Rod

1

30 Plastic

Sleeve

1

31 Pop-Up

Drain

1

32

Upper Drain Flange

1

33 Washer

1

34 Formed

Gasket

1

35 Drain

Nut

1

36 Washer

1

37

Lower Drain Body

1

38 Tailpiece

1
