MSI CellScale
®
System • 9750A User Guide Page 63
MEASUREMENT SYSTEMS INTERNATIONAL
Firmware Version 5-XX for 2450 Modems
Output Weight Value and mode @W 1=current weight
2=gross
3=net
4=tare
5=total
6=# of totals
7= total, # of totals
8=reserved
9=last totaled weight
%= Per Cent of Capacity
@W1
@W2
@W3
@W4
@W5
@W6
@W7
@W9
@W%
**20.002*LB***GROSS*
Length: 20, fi xed. Leading zeros suppressed
**205.08*KG***GROSS*
Length: 20, fi xed. Leading zeros suppressed
*1188.50*G****NET***
Length: 20, fi xed. Leading zeros suppressed
****5000*TNE*TARE**
Length: 20, fi xed. Leading zeros suppressed
*432534.85*KG***TOTAL*
Length: 22, fi xed. Leading zeros suppressed
12345*T*CNT*
Length: 12, fi xed. Leading zeros suppressed
*432534.85*KG***TOTAL,12345*T*CNT*
Length: 34, fi xed. Leading zeros suppressed
**200.05*KG***GROSS+*
or NET+ in NetMode
Length: 20, fi xed. Leading zeros suppressed
***31.04*%****G-CAP*
or N-CAP in Net Mode
Length: 20, fi xed. Leading zeros suppressed
Output a statistics value
@X
@X1
@X2
@X3
@X4
@X5
@X6
@X7
@X8
**13.350
***3.200
**16.650
***2.392
***32.50
4263285.55
*****52.50
*123434
1=Average weight
2=Minimum
3=Maximum
4=Standard Deviation
5=Coeff of Variance
6=Grand Total
7=Grand Average
8=# of Grand Totals
Output a statistics value and
mode
@Y
@Y1
@Y2
@Y3
@Y4
@Y5
@Y6
@Y7
@Y8
**13.350*LB***AVG***
***3.200*LB***MIN***
**16.650*LB***MAX***
***2.392*LB***STDDEV
***32.50*LB***CO-VAR
4263285.55*LB***G-TOTL
*****52.50*LB***G-AVG*
*123434*G-CNT*
1=Average weight
2=Minimum
3=Maximum
4=Standard Deviation
5=Coeff of Variance
6=Grand Total
7=Grand Average
8=# of Grand Totals
Output All ID Statistics and
grand statistics
@Z
none
@Z
Outputs formatted data of all statistics for valid
product IDs. Parameters include totals, number
of samples, average, min, max, std dev, etc. for
each product ID, and grand total with statistics
for all product IDs combined.
Description
Cmd
Command Suffi x
Input
examples
Output examples & comments
*= a space or place holder
Product ID number: 1
Product ID name:
Product ID ch-sub: Ch
1-1
5 T CNT
130.0 LB TOTAL
26.0 LB AVG
10.0 LB MIN 8
50.0 LB MAX
15.2 LB STDDEV
58.33 % CO.VAR
Product ID number: 2
Product ID name:
Product ID ch-sub: Ch
1-2
0 T CNT
0.00 MTON TOTAL
0.00 MTON AVG
0.00 MTON MIN
0.00 MTON MAX
0.00 MTON STDDEV
0.00 % CO.VAR
5 G-CNT
130.0 LB G-TOTL
26.0 LB G-AVG
Typical @Z Output
!st Product ID Printout
2nd Product ID Printout
...after fi nal ID, Grand Total printout
