MSI CellScale
®
System • 9750A User Guide Page 19
MEASUREMENT SYSTEMS INTERNATIONAL
Firmware Version 5-XX for 2450 Modems
To Switch Between Multi-Channel Display and Single Channel Displays
1) Highlight the channel you wish to see in the single channel mode by pressing the UP (
^
) or DOWN (
v
)
cursor keys.
2) Once highlighted press
DISPLAY
. The highlighted channel will appear in the single channel mode.
3) Perform any scale function while in the single channel mode.
4) To return to the multi-channel display, press
DISPLAY
.
Multi-Channel Page Display
When a multi-channel display mode is selected that shows fewer channels than are available from the CellScale,
the user can view all channels with the page mode.
Any channel can appear on any page by changing the preset channel using the “To Change Scale Channel...”
procedure. This allows a primary channel to show always, and secondary channels to change using the
ALPHA
key. This applies very well to the 3 channel preset display where one channel is large and the other 2 channels
are small.
To Change to the Next Page
Press the
ALPHA
key. The next group of channels appears. The action of the
ALPHA
key is circular, return-
ing to page 1 after the last page.
To Copy the Current Page
Sometimes it is advantageous to copy the current page and then make channel changes on the new page.
1) Press the
ENTER
key. The entire screen will reverse.
2) Press the
ALPHA
key. The new copied page will appear. Make modifi cations with the enter channel pro-
cedures as desired.
To Delete the Current Page
1) Press the
[0]
(SPACE)
key.
2) Press the
ALPHA
key. The current page will be deleted and the display will revert to the fi rst page.
The 9750A will not allow the deletion of the last remaining page.
To Move Around in Pages
If you have many preset pages, you can move directly to pages by number entry.
1) Enter the number corresponding to the page you wish to see.
2) Press the
ALPHA
key. The new page will appear.
1) In single channel mode, go to step 2. In multi-channel mode, highlight a channel
with the up (
^
) or down (
v
) cursor keys to make it active.
2) Press
ZERO
. The weight reading must be stable within the motion window for
the zero function to work. The display temporarily reads “ZEROING” and then
“ZEROED” after the CellScale acknowledges the command. The scale digits
display 0 (or 0.0 or 0.00, etc..). The backup memory in the CellScale stores the
zero reading, and can restore it even if power fails.
The “ZEROING” and “ZEROED” messages may not be displayed on every zero request if the CellScale responds
instantly, but the scale will zero.
ZERO
CLR
0
ZEROING
ZEROED
ZERO
Sets the zero reading of the scale. Use the
ZERO
key to take out small deviations in zero when the scale is
unloaded. (See “TARE SET” for zeroing (Taring) package or pallet weights)
To Zero
Zero Rules for Use:
1) Works in GROSS mode or NET mode. Zeroing while in Net mode will zero the gross weight causing the display
to show the negative Tare value.
2) The scale must be stable within the Motion window. The scale will not zero if the motion detect annunciator
is on. The CellScale will “remember” that it has a zero request for 2 seconds. If motion clears in that time,
