it’s Host3 print string.
Send to CS Host 4
........Tells the CellScale to output it’s Host1 print string.
Print & Send Host 4
.....Outputs Comm 1 print string to the DE-9 connector, and tells the CellScale to output
it’s Host4 print string.
Send to CS Host 5
........Tells the CellScale to output it’s Host5 print string.
Print & Send Host5
......Outputs Comm 1 print string to the DE-9 connector, and tells the CellScale to output
it’s Host5 print string.
Print Aux to Comm 1
...Sends the Aux string directly to Comm Port 1
Start/Stop Comm 1
.......If the Comm 1 print string is set to an automatic or continuous output mode, this func-
tion key will act as a start/stop print key.
5 – Edit Print Strings and Bar Code Group
Edit CS Print String
......Allows direct entry into the Master CellScale Comm 1 print string edit screen. This
print string outputs on the CellScale Comm Port 1 connector.
Edit Print String
............Allows direct entry into the 9750A Comm 1 print string edit screen. This is the print
string used for Data Logging as well as printing out the 9750A Comm Port.
Edit CS Host 3 String
..Allows the 9750A to edit the CellScales RF Host 3 string which is used to communicate
with remote modems.
Edit CS Host 4 String
..Allows the 9750A to edit the CellScales RF Host 4 string which is used to communicate
with remote modems.
Edit CS Host 5 String
..Allows the 9750A to edit the CellScales RF Host 5 string which is used to communicate
with remote modems.
Get BarCode 1
...............Opens Bar Code 1’s input entry buffer to receive data from the Comm Port.
Get BarCode 2
...............Opens Bar Code 2’s input entry buffer to receive data from the Comm Port.
Get BarCode 3
...............Opens Bar Code 3’s input entry buffer to receive data from the Comm Port.
Get BarCode 4
...............Opens Bar Code 4’s input entry buffer to receive data from the Comm Port.
Get All BarCodes
..........Programs key to open all enabled bar code buffers in order. All bar codes must be
assigned a length in the autostart bar code menu. Can include ID print strings.
6 – Text Messaging Group
Send Message to 1
.......Sends Message String to CellScale Comm Port 1.
Send Message to All
....Sends Message String to CellScale Comm Port 1 and to CellScale RF Host 3, 4, and
5.
Send Message to 3
.......Sends Message String to CellScale RF Host 3.
Send Message to 4
.......Sends Message String to CellScale RF Host 4.
Send Message to 5
.......Sends Message String to CellScale RF Host 5.
Reply Last Message
....Send Reply to source of last received message.
7 – Data Logging Group
Store to Memory 1
........Outputs Comm 1 print string to data logging memory 1.
Store to Memory 2
........Outputs Comm 1 print string to data logging memory 2.
Store to Memory
...........Outputs Comm 1 print string to data logging memory 1 or 2 depending on the setting
in the Data Logging Control menu.
Aux to Memory 1
..........Outputs the Auxiliary string to data logging memory 1.
Aux to Memory 2
..........Outputs the Auxiliary string to data logging memory 2.
Aux to Memory
..............Outputs the Auxiliary string to data logging memory 1 or 2 depending on the setting
in the Data Logging Control menu.
Data Logging Cntl
........Brings up the Data Logging control menu for uploading and erasing data.
8 – Set Point Group
Enable Set Points
.........Enables the Set Points by F-Key push. Used for Start.
Disable Set Points
........Disables the Set Points by F-Key push. Used for Stop.
Enable/Disable SPs
......Push On/Push Off control of Set Points
Set Pt Momentary
.........Enables remote Set Point Relay while being pushed. Sub-menu specifi es which Set
Point is forced on.
Set Pt On
.........................Turns remote Set Point Relay on. Specify Set Point in Sub-menu.
Set Pt Off
........................Turns remote Set Pont Relay off. Specify Set Point in Sub-menu.
Set Pt Push On/Off
.......Toggles Set Point Relay on/off. Specify Set Point in Sub-menu.
