MSI CellScale
®
System • 9750A User Guide Page 61
MEASUREMENT SYSTEMS INTERNATIONAL
Firmware Version 5-XX for 2450 Modems
SERIAL OUTPUT “@” COMMANDS
The printer formatting “@” commands and their data confi gurations are as follows:
Output Spaces
@B
# where “#” is the number
of spaces from 1-255
@B100
100 spaces inserted in
the string
Output ID Code
@C
1=ID and code #
2=Code # only
ID CODE **1
*14 Outputs the current ID number only.
@C1
Output Date
@D
1=ddmmmyy
2=mm/dd/yy
3=dd/mm/yy
4=Day of Wk
5=ddmmmyyyy
6=mm/dd/yyyy
7=dd/mm/yyyy
8=yyyymmdd (ISO)
@D1
@D2
@D3
@D4
@D5
@D6
@D7
@D8
30SEP02*
09/30/06
30/09/06
SATURDAY**
30SEP2006*
09/30/2006
30/09/2006
20060930
Output End-of-line String
@E
None
@E
Outputs End-of-line string. Up to 64 bytes.
Output Horizontal Tabs
@H
# where “#” is the number
of tabs from 1-255
@H10;
Outputs 10 horizontal tabs. Terminate with
semicolon for less than 3 digits.
Output Start-of-line String
@F
None
@F
Outputs Start-of-line string. Up to 64 bytes.
Select Active Channel
@nn
where “nn” is the channel
list location 01-32
@05
@26
Selects Channel List
location 5.
Selects location 26
All commands that are
Selects Channel List
Selects Channel List
channel specific are
directed to this Channel
Description
Cmd
Command Suffi x
Input
examples
Output examples & comments
*= a space or place holder
Output an “@” sign
@@
@@
@ The CellScale uses the @ sign for specifi c
embedded commands, this command allows the
outputing of @.
None
Reset the host parser
;
None
;
This command can be used at any time to reset
the command parser
Change to previous channel
w/ Labels
@-
None
@-
Switches to previous channel and outputs SC
number, LC# and LC Name
Change to next channel
w/ Labels
@+
None
@+
Switches to next channel and outputs SC
number, LC# and LC Name
Query for current scan list posi-
tion
@?
1=Current Scan Index
2=Current Display Index
@?
Outputs SC number, LC# and LC Name
SC 1, CH 1-1, Name of Scale****
Name of scale up to 20 characters
Change to next channel
(no Label)
@#
None
@#
Switches to next channel in scan list.
Change to previous channel
(no Label)
@!
None
@!
Switches to previous channel in scan list.
Output Annunciators
@A
1=Battery Level
2=Center of Zero
3=Motion Status
4=OK to Total Status
5=Net./Gross Status
6=Channel Status
7=9750 Battery Voltage
8=Batt normal or low
9=Int temperature
@A1
@A2
@A3
@A4
@A5
@A6
@A7
@A8
@A9
BAT1 =Bat >1% BAT2 =Bat >10%
BAT3 =Bat >25%
COZN =Not COZ COZY =COZ
MTNN=No Motion MTNY=In Motion
TTLN=Not OK to Total TTLY=OK to Total
NET*=Net mode GRS*=Gross mode
ACTN = Not Active ACTY = Active
BAT 13.2 Volts
BATTERY NORMAL or BATTERY LOW
or
or
TEMP 30C measures internal temp of 9750
