Weather front Explanation
Stationary front
(red and blue line with red
semi-circles and blue
triangles)
The weather front moves minimally. The weather remains
changeable in this area.
Occlusion
(purple line with purple
semi-circles and
triangles)
An occlusion arises when the faster cold front catches up and
joins the warm front ahead of it. The weather remains
changeable and rainy within an occlusion.
: Position on the forecast path
; Current position of the cyclone
= Position on the previous path
To display the track of a storm:
X Activate the Tropical Storm Tracking Tropical Storm Tracking display level (
Y
page 266).
If weather data is available, the weather map will then display the track of the storm.
i A dotted line shows the previous path and the forecast path of a tropical low-pressure
area (cyclone).
SIRIUS Weather
269
SIRIUS
Weather
