7. Product Description

Micro Client 3 – User’s Guide (Version 1.0)

7.1.1. USB Interface Connector on the Front Side of the MC 3 104/121/150/170 Systems

This USB 2.0 connector allows you to connect different USB-compatible devices to the MC 3 system. The USB connector is
covered by an elastic captive rubber coat. The rubber coat prevents the penetration of fluid if no device is connected.

The MC 3 104/121/150/170 systems only comply with IP65 protection class at the front side, if the front
side USB connector is covered by the elastic captive rubber coat.

The USB interface connector is available only on the front side of the MC 3 104/121/150/170 system.
The MC 3W 156 system is not equipped with the USB interface on the front side.

7.1.2. MC 3 104/121/150/170 Systems - Front Plate Version

All MC 3 104/121/150/170 system versions are suitable for installation in an instrument panel or other cabinet.
At the front side of the 104/121/150/170 system, an aluminum front plate with polyester front foil is located.

For the outline dimensions of display unit of your system (MC 3 104/121/150/170) please refer to the chapter 9.3
“Mechanical Specifications”
.

7.1.2.1.

TFT Display 10.4"/12.1"/15"/17" with Touch Screen (resistive)

Depending on the ordered MC 3 system the built-in display is a 10.4"/12.1"/15"/17" size TFT display with corresponding
resistive touch screen. The touch screen is USB connected.

For technical specification of the built-in display refer to the chapter 9 “Technical Data”.

The display is equipped with a resistive touch screen. The touch screen offers the same degree of user comfort as the mouse
buttons.
The surface of the display is also mechanically protected through the touch screen. The touch screen (USB connected)
registers contacts of a finger or a pen and allows moving the mouse pointer. This functions only by integration of the
necessary software. The corresponding touch screen driver for your operating system is installed on your MC 3 system.

Do not use a hard or a pointed object (like screw drivers) to operate the touch screen, since it can damage
the touch screen surface.
The front panel (MC 3 104/121/150/170) and the touch screen are covered by a plastic overlay and care
should be taken when cleaning it (see the chapter 7.1.4 “Touch Screen Care and Cleaning”).

18
