SECTION VI A - DOOR FRAME INSTALLATION
Apply sealant to the ends of the header and vertical glazing adaptor as shown in
fasten into place with #STT6 screws, 4" from the ends and 12" on center maximum.
Apply a thin bead of sealant vertically to set the screw applied glazing stop into. Then
Apply sealant to the ends of the header and install with the screws provided.
Attach the header to the condition with 1/4" diameter fasteners minimum, 6" from
Temporarily locate the header / clip combination at the correct mounting position to
locate and drill the mounting holes for the clip into the jamb.
Slide the header clip onto the end of the header. Drill and fasten the clip to the header
TRANSOM HEADER AND APPLIED TRANSOM GLAZING
Fig. 63 above.
SET IN A BEAD OF SEALANT VERTICALLY
the jambs and 16" on center maximum.
with the screws provided in the clip package.
9295
SCREWS
#STT6
SEALANT
SEALANT
BAB 11/2001
[FIG. 63]
CONT.
PAGE 50
9539 @ 902
(901 SIMILIAR)
K267 CLIP @ 902
K277 CLIP @ 901
9592 DOOR JAMB @ 902
(901 SIMILIAR)
9484 HEAD CAN
AT THE SIDE LITE
TYP. @ 902
(901 SIMILIAR)
