Butt glazed verticals, Intermediate horizont, Step 1) – EFCO 904 Series User Manual
Page 34: Fig. 32
DPS 7/2001
See Fig. 32 below.
cans similar to the captured mullion. Then it is tapped against the can
The vertical butt glazed mullion is set into the rear portion of the HEAD/SILL
fillers as before. Proceed to the next vertical.
SECTION IV C - INSTALLATION
SILL CAN
STEP 1)
GLAZED MULLION
VERTICAL BUTT
[FIG. 32]
CAN FILLER
INSTALLED
BUTT GLAZED VERTICALS
PAGE 32
