901/902 - 7260/7260 135 DEG. INSIDE - K491
901/902 - 7260/7260 135 DEG. OUTSIDE - K490
901/902 - 7255/7256 90 DEG. INSIDE OR OUTSIDE - K493
BUTT GLAZED VERTICALS
90 CORNER SHOWN BELOW IN FIG. 35, OTHERS SIMILAR.
FLAT HEAD SCREW SUPPLIED IN THE SHEAR BLOCK PACKAGE.
ATTACH THE HORIZONTAL TO THE SHEAR BLOCKS WITH THE
TYPICAL SHEAR BLOCK ATTACHMENT FOR S.S.G. CORNERS.
SHEAR BLOCK
PACKAGE
[FIG. 35]
K493
8583 HORIZ. SHOWN
OTHER HORIZ. TYP.
STEP 3)
SECTION IV C - INSTALLATION
MULLION
DPS 7/2001
3/4" TO TOP
OTHERS SIMILAR
MULLION SHOWN
S.S.G. CORNER
7255/7256
OF HORIZONTAL
(cont.)
EDGE OF
PAGE 34
STK4
1.132"
2.117
STV2
