Page 27: V glazing, Head and sill can anchoring, Fig. 20, Step 1)
#9468 - S904
DPS 7/2001
Fasten head and sill cans to surround through back portion
of the can shape. Seal over all fastener heads in sill can.
HEAD AND SILL CAN ANCHORING
#9476 - S903
SHIMS ARE OPTIONAL WITH
#9484 - S902
#9479 - S901
THESE HEAD/SILL CANS
SEALANT
[FIG. 20]
END DAMS AT
JAMBS ONLY
SECTION IV A - INSTALLATION
See Fig. 20 below.
STEP 1)
PAGE 25
1/4" DIAMETER
MINIMUM FASTENERS
AT 3" EACH SIDE OF
VERTICAL MULLIONS
AND 24" MAXIMUM
ON CENTER.
(TYPICAL ALL SYSTEMS)
902/904 - HN31
END DAMS
901/903 - HN30
END DAMS
