Fig. 45 below and Fig. 46 on page 40.
Follow the glass setting procedure as detailed in
- LAST -
INSTALL THIS UNIT
[FIG. 45]
GASKET RUNS THRU
MULLION
BUTT GLAZED
STEP 6)
AT VERTICALS
[FIG. 44]
3/8" x 1/2" TAPE
WM10
DPS 7/2001
INSTALL THIS UNIT
- 2nd TO LAST -
GLASS STOP
JAMB
JAMB
1/2"
head can gasket track to sill can gasket track, located on the butt
Apply WM10 (2 sided tape) to the butt glazed mullion vertically, from
DO NOT remove the exterior protective film until the glass unit has been
glazed mullion as shown below.
set and positioned correctly.
STEP 5)
PAGE 39
SECTION V A - GLAZING PROCEDURES
FOR BUTT GLAZED VERTICAL
(CONT.)
