EFCO 403 Series Storefront - Manual (Page 90)

EFCO CORPORATION 1/2013 PART NO. Y001 Page 90 of 94
Series 401,402, & 403 Installation Instructions
B) Push glass back to the interior side.
A) Remove interior and exterior glazing gasket.
ANTIWALK BLOCK
STEP 5) ANTIWALK BLOCK DEGLAZING
D) Recenter the glass unit to maintain
only.
exterior at midlite and deep pocket
in Fig. 107 below and insert from the
C) Stretch the antiwalk block as shown
steps on page 88.
B) Position glass as described in the
steps on page 87.
A) Install interior gasket following the
STEP 4) ANTIWALK BLOCK INSTALLATION
HN54
HN52
HN50
SECTION V: C. OUTSIDE GLAZING
hook shaft tool from exterior side.
C) Remove antiwalk block with sharp
REMOVE FROM THIS SIDE
ANTIWALK BLOCK
EXTERIOR
INTERIOR
FIG. # 107
FIG. # 108
E) Install exterior gasket.
equal glass bite all around.
