Fig. # 82, Step 2), Fig. # 81 – EFCO 403 Series Storefront User Manual

Page 75

EFCO CORPORATION 1/2013 PART NO. Y001

Page 75 of 94

Series 401,402, & 403 Installation Instructions

WATER ONTO 9160

Fig. # 82

(APPROXIMATELY 1/4" THICK)

INTERIOR TO FLOOR.

AND TOOL TO SEAL

TO NEXT VERTICAL MULLION

SEALANT BEAD CONTINUES

glazing pocket to the next vertical.

continuous bead of sealant on the

WITH SEALANT TO DIVERT

FILL GLAZING POCKET

Proceed to page 76.

floor at the inside line of the

Start at the door jamb and run a

STEP 2)

9109

DOOR JAMB

Fig. # 81

STT7

RIE

9161

9160 SILL

SIDE LITE BASE INSTALLATION

2 1/2" ADJUSTABLE HEIGHT

Assemble the base verticals to the base horizontal sill member.
Refer to pages 54 and 55 for preps. See figures below.

STEP 1)
