EFCO CORPORATION 1/2013 PART NO. Y001 Page 66 of 94
Series 401,402, & 403 Installation Instructions
Fig. # 68
towards the opposite end. See Fig. # 69 below.
If a corner is required, installation will start at the corner and work
AT CORNERS
Fig. # 69
SHEAR BLOCK
APPLICATIONS
STEP 6)
8696
8697
SECTION IV: C.
The frame units can be installed in a number of different ways.
SYSTEMS INSTALLATION
9121
9221
9314
9120
9220
9320
See Fig. #68 below for single unit setting technique.
See page 67 for panel unit setting technique.
STEP 5)
SCREW SPLINE AND SHEAR BLOCK
NOTE:
S129
S129
