EFCO CORPORATION 1/2013 PART NO. Y001

Page 44 of 94

Series 401,402, & 403 Installation Instructions

Drill as indicated thru one

wall using #2 drill (.221 dia.)

for BOTH S402 and S403.

K173 for S402

HORIZONTAL and SILL END
PREP FOR ATTACHMENT

TO SHEAR BLOCKS

DJ02 DRILL JIG APPLICATION for

S402 and S403 SYSTEM

S4

02

A

ND

S

40

3

DR

ILL

DJ02

DJ02

S402 ONLY

DRI

LL

S403 ONLY

DRILL

K172 for S403

SECTION III: B. SHEAR BLOCK FABRICATION

Fig. #16

Fig. #17
