Fig. # 56 fig. # 55, Fig. # 53, Fig. # 52 – EFCO 403 Series Storefront User Manual
Page 60: Fig. # 54
EFCO CORPORATION 1/2013 PART NO. Y001
Page 60 of 94
Series 401,402, & 403 Installation Instructions
These recommendations are for general erection procedures only. For
actual job conditions, see the details on the shop drawings. For perimeter
anchor type and spacing, refer to the approved shop drawings or consult
the project design professional
.
ALSO SEE THE DOOR INSTALLATION INSTRUCTIONS #Y015.
the back of the threshold and sides of
EXTERIOR
Fig. # 56
Fig. # 55
At the option of the erector,
Fig. # 53
located at the fasteners.
Attach through the header
with flat head screws
Fig. # 52
SECTION IV: A. DOOR FRAME INSTALLATION
located 6" from the ends and
use the perimeter adaptor
continuously or 3" long pieces
INTERIOR
at jambs.
Attach through the threshold
with flat head screws.
Continuous bead of sealant at
When the jamb members are plumb and
anchored, snap-in the door stop.
Anchor through the glazing pocket
24" on center, maximum spacing.
the jambs and tied into mullion sealant
Door jamb set in sealant.
at the condition.
Transom bar shown,
jamb anchoring using
fin stop jamb
is similar.
as shown, from jamb to jamb
Seal the interior glass stop
at the transom bar.
Fig. # 54
TYP. TRANSOM
GLASS STOP
9126
Do not seal the
exterior glass stop,
this will allow weepage.
