EFCO CORPORATION 1/2013 PART NO. Y001 Page 76 of 94
Series 401,402, & 403 Installation Instructions
These recommendations are for general erection procedures only. For actual
job conditions, see the details on the shop drawings. For perimeter anchor
type and spacing, refer to the approved shop drawings or consult the project
design professional
.
STU5
Fig. # 83
1/4" diameter weep
holes at 1/4 points
Continuous
bead of sealant
9160
screws with sealant
Cover the heads of all attachment
SIDE LITE BASE INSTALLATION
2 1/2" ADJUSTABLE HEIGHT
(# 8 x 2 " PL.PH.MS.), then anchor the base to the floor.
Fig. # 83 below. Attach this to the vertical framing with STU5 screws
Place partially assembled base on the bead of sealant as shown in
9161
STEP 3)
SECTION IV: E.
