EFCO CORPORATION 1/2013 PART NO. Y001 Page 70 of 94
Series 401,402, & 403 Installation Instructions
These recommendations are for general erection procedures only. For actual
job conditions, see the details on the shop drawings. For perimeter anchor
type and spacing, refer to the approved shop drawings or consult the project
design professional
.
and the sill flashing at the exterior. This is to allow for water migration
to the exterior without drilling weep holes.
This is to allow for water migration to the exterior without drilling weep holes.
S F098
FLASHING CLIP
SEAL PERIMETER JOINT
Fig. # 75
JAMB TO JAMB
BEAD OF SEALANT
S
9957
TYP. SILL
9957
SEAL PERIMETER JOINT
1G64 I-BAR
1G65 I-BAR
1G85 w/ CLIP
BEAD OF SEALANT
JAMB TO JAMB
TYP. SILL
S
S
SYSTEMS INSTALLATION
SCREW SPLINE AND SHEAR BLOCK
Do not seal between the sill horizontal
STANDARD INSTALLATION
SECTION IV: C.
and the sill flashing at the exterior.
Do not seal between the sill horizontal
CLIP INSTALLATION
Seal unit as shown in details below.
SYSTEM ANCHORING
& PERIMETER SEALING
SIMILAR
(REFER TO
PERIMETER
ADAPTOR
FIG. # 71
PAGE 67)
HEAD & JAMBS
SEAL PERIMETER JOINT
When using the sill flashing clip
(F098), fastening through the
sill member is not necessary.
PERIMETER ADAPTOR (REFER
TO FIG. # 72 PAGE 68)
