EFCO 403 Series Storefront - Manual (Page 63)

EFCO CORPORATION 1/2013 PART NO. Y001 Page 63 of 94
Series 401,402, & 403 Installation Instructions
These recommendations are for general erection procedures only. For actual
job conditions, see the details on the shop drawings. For perimeter anchor
type and spacing, refer to the approved shop drawings or consult the project
design professional
.
12" MIN.
#9957 sill flashing shown.
attachment screws with sealant.
Refer to the parts identification
section for a particular application.
TO
SP
LIC
E J
OIN
T
TY
P.
Fig. # 63
12"
MIN
.
3"
Cover the heads of all
SEALANT
Fig. # 62
TO SPLICE JOINT
Cover the heads of all
FIG. #60
3/8"
K293
TYP.
3"
If a corner is required, miter the flashing to the required angle
and then install as shown in the figures below.
of the sill flashing splice.
Locate fasteners 3" from any corner and 1 1/2" from the edge
1 1/2" 1 1/2"
SEE
6" MIN.
STEP 3)
with sealant.
SEALANT
attachment screws
SECTION IV: B. SILL FLASHING INSTALLATION
