Series 401,402, & 403 Installation Instructions
Part # Y015
NOTE: If NO entrance frame is required, proceed to part "B"
NOTE: If an entrance frame is required, it must be installed first.
Anchor the door frame as indicated below in Fig. # 51 and also in
Set assembled door frame in opening, plumb and level.
Correctly locate the entrance frame in the opening.
SECTION IV: A. DOOR FRAME INSTALLATION
Door Installation Instructions
For bottom pivot prep see
K-153/K-154 Threshold Clip & Screws
@ Offset Pivots & Butt Hinges
@ Concealed Rod Panic
THRESHOLD
(9950)
Fig. # 51
Fig's. # 52 through Fig. # 56 on page 60.
floor and is cut longer
than any other vertical
The door jamb runs to the
member.
NOTE:
SIDE LITE SILL
STEP 3)
STEP 2)
STEP 1)
Continuous bead
of sealant
of this section.
K-124/K-125 Threshold Clip & Screws
Apply a bead of sealant around the interior portion of the jamb
STEP 4)
to set the member into. Then marry the side lite sealant or condition
sealant into the bead of sealant to be applied under the threshold.
The concept is to have a continuous bead of sealant at the interior,
connected from the sill flashing/condition through the door jamb
and continuing under the threshold to the opposite jamb and so on.
