Dyno Placement
The first step to installing your Dynojet
Dynamometer is to decide where you want to
position the Dyno in your shop. Do you want to
drive the vehicle into the shop forward, or back it
in? Do you have equipment or tools located in
your shop that would be more convenient to use
based on the placement of the Dyno? There are
two basic methods to position the Dyno in your
shop.
Method 1
Method 2
This image represents a front
wheel drive car on a dyno
away from the garage door.
This image represents a front
wheel drive car on a dyno
near the garage door.
This image represents a rear
wheel drive car on a dyno
away from the garage door.
This image represents a rear
wheel drive car on a dyno
near the garage door.
