Step 7
The Breakout Board jumper settings are preset,
though it is important that they be checked to
ensure they are set for your application.
The jumpers circled in white above may need
to be changed to look like one of the drawings
below. (The wires in the picture above reflect
a proportional air install. Ignore them if you
are installing standard air.)
Proportional Air Jumper Settings.
Standard Air Jumper Settings.
