Document #98219100 3 - 5
Step 3
Mount the brakes on the dyno frame. Use three
bolts, three nuts, and three lock washers on each
brake weldment.
Remove the nuts and lock washers from the
dyno frame leaving the bolts in place.
Place the brake weldments over the bolts on
the frame.
Finish the installation of the brake weldments
with the nuts and lock washers.
Step 4
Install the air hose between the brakes, using the
ports on the sides of the air canisters.
