Wiring the dyno – Dynojet 248x: Pit Installation Guide User Manual
Page 28
3 - 6
Document #98219100
Wiring the Dyno
The following hardware and wires are shipped in
boxes with the dyno except the DynoWare EX+
(A) that is shipped separately with the WinPEP
software. Refer to the following page for item
descriptions.
Basic Kit
Additional for the Optional Proportional Air
Brake System
M
Q
O
N
R
P
K
C
D
E
F
G
H
J2
J1
I
B
A
L
