3 - 24 Document #98219100
Install the Dyno Cover(s)
Use the following steps to install the dyno
cover(s):
Step 1
Check the anchor bolts and lateral supports to
make sure they are tight. Install the dyno cover.
Step 2
Check the brakes. The DynoWare Stack must be
on to release the brakes. Slowly rotate the drums
(this can be done manually) then press the brake
button (the red button on the Remote Pendant).
The button should light up and engage the brakes
stopping the drums. Press the button again and
the light will go off, disengaging the brake. If the
brakes do not engage, make sure the pressure
gauge Air Brake Regulator is set to 40 PSI (276
kPa), and check all connections.
