Table 1-8
Rear Panel Connectors
Ref.
Component
Function
1
Voltage Select Switch
Switches voltage between 115 V (U.S.) and 230 V to meet geographical requirements.
2
Serial Connector
Connects a serial device, such as a serial printer.
3
Parallel Connector
Connects a parallel device, such as a parallel printer.
4
Keyboard Connector
Connects the keyboard.
5
Mouse Connector
Connects the mouse.
6
Universal Serial Bus Connector Connects the computer to any peripheral while the computer is operating. Is a fully
functional Plug and Play connector.
7
Monitor Connector
Connects a monitor to an embedded graphics controller.
8
Power Cord Connector
Connects the computer to an electrical power outlet.
9
Microphone Connector*
Connects a microphone for recording sound and voice.
:
Line-In Audio Connector*
Connects an external audio input device.
;
Line-Out Audio Connector*
Connects an external audio output device, such as powered speakers, or a cassette
tape recorder.
<
Headphone Connector*
Connects headphones (not suitable for unpowered speakers).
* Audio features are available on select models only.
