Compaq Deskpro 2000 Series of Personal Computers E-1
appendix E
D
IAGNOSTIC
E
RROR
C
ODES
Diagnostic error codes occur if the system recognizes a problem while running the Compaq
Diagnostics program. These error codes help identify possibly defective subassemblies.
Table E-1 lists the device codes (AABB-CC) and the subtest range (AABB-CC) covered by Compaq
Diagnostics Tests. Some codes will not apply to the computers described in this manual and will not
be detailed in the tables that follow.
Table E-1
Summary of Test Error Codes
Error Code
Range
Device Description
Error Code
Range
Device Description
0100 - 0199 Processor (P1) 3113 - 3199 Third Processor (P3)
0200 - 0215 Memory 3206 Audio System
0301 - 0304 Keyboard 3300 - 3333 Multimedia
0401 - 0498 Parallel Port 3400 - 3401 TV Tuner Board
0501 - 0516 Video Display Unit 4113 - 4199 Fourth Processor
0600 - 0699 Diskette Drive 5100 - 5130 Plasma Display System
0802 - 0824 Monochrome Video Board 5234 - 5240 Advanced Color Graphics (AGC)
1101 - 1109 Serial Port 6000 - 6089 Network Card
1201 - 1210 Modem 6500 - 6599 SCSI Hard Drives
1700 - 1799 Hard Drive 6600 - 6699 SCSI CD-ROM Drives
1900 - 1906 Tape Drive 6700 - 6799 SCSI Tape Drives
2113 - 2199 Second Processor (P2) 7000 Server Manager/R Board
2402 - 2480 Enhanced Color Graphics (ECG/VGA) 8601 - 8602 Auxiliary Input Interface
2502 - 2502 Pen/Digitizer 8700 - 8702 Game Port
