Rally Armor 05 to 09 Subaru Legacy - Manual (Page 2)

2
Tip: The hardware is quite strong and self threading but over‐tightening the clips beyond their limit is not recommended.
Tip: To check any non‐standard wheel clearance, turn the steering wheel from lock to lock while viewing the wheel well area at different
intervals.
Rear Mud Flap Installation
Tip: Although removal of th
crewdriver and jacking up the rear of the vehicle thereby lowering the wheel and facilitating access to the area for easier installation.
1. Remove OEM splash guard if present. Position two polygon clips (PolCl) over outer rear mounting slots #4 and #5. Remove inner fast
located in the #6 slot. This fastener is removed by prying out the inner tab first then removing the outer assembly (Figure G).
2. Place insert (Ins) into mounting slot #6 until flush. (Figure H).
3. Place rear mud flap with logo facing the rear of the vehicle with
vehicle. Thread short screws (1SS) with washers through mud flap slots into rear mounting points #4, #5 and #6.
*
e rear tire can ease installation, removal is not necessary. The installation can be completed using an offset
s
ener
the mud flap mounting holes aligned to the corresponding points on the
Do not fully tighten.* You will need to adjust the mud flap before tightening the screws.
4. Confirm the edge of the flap is perpendicular to the ground. If needed, make slight adjus
the flap. Check each incremental adjustment by walking away from the vehicle and looking at the mud flap directly behind in relation to the
ground and the body of the vehicle. When flap is correctly aligned, tighten all hardware
only until snug (Figure I).
tments by shifting the upper or lower portions of
Tip: The hardware is quite strong and self threading but over‐tightening the clips beyond their limit is not recommended.
Tip: The inner mounting slot #6 on the rear mud flap is extended to allow for installation on both Outback and other Legacy variations.
. Repeat the instructions for the other side of the vehicle to complete mud flap installation.
Legacy UR installation P. Version 1.0‐ 11.13.2008
5
