CY7C68013A, CY7C68014A
CY7C68015A, CY7C68016A
Document #: 38-08032 Rev. *L Page 37 of 62
9. DC Characteristics
9.1 USB Transceiver
USB 2.0 compliant in full-speed and high-speed modes.
10. AC Electrical Characteristics
10.1 USB Transceiver
USB 2.0 compliant in full-speed and high-speed modes.
Table 14. DC Characteristics
Parameter Description Conditions Min Typ Max Unit
VCC Supply Voltage 3.00 3.3 3.60 V
VCC Ramp Up 0 to 3.3V 200
μs
V
IH
Input HIGH Voltage 2 5.25 V
V
IL
Input LOW Voltage –0.5 0.8 V
V
IH_X
Crystal Input HIGH Voltage 2 5.25 V
V
IL_X
Crystal Input LOW Voltage –0.5 0.8 V
I
I
Input Leakage Current 0< V
IN
< VCC ±10
μA
V
OH
Output Voltage HIGH I
OUT
= 4 mA 2.4 V
V
OL
Output LOW Voltage I
OUT
= –4 mA 0.4 V
I
OH
Output Current HIGH 4 mA
I
OL
Output Current LOW 4 mA
C
IN
Input Pin Capacitance Except D+/D– 10 pF
D+/D– 15 pF
I
SUSP
Suspend Current Connected 300 380
[16] μA
CY7C68014/CY7C68016 Disconnected 100 150 [16] μA
Suspend Current Connected 0.5 1.2 [16] mA
CY7C68013/CY7C68015 Disconnected 0.3 1.0
[16]
mA
I
CC
Supply Current 8051 running, connected to USB HS 50 85 mA
8051 running, connected to USB FS 35 65 mA
T
RESET
Reset Time after Valid Power VCC min = 3.0V 5.0 mS
Pin Reset after powered on 200
μS
Note
16. Measured at Max VCC, 25°C.
