Chapter 5: Local Management
5-40 2H28-08R SmartSwitch 2208 User’s Guide
5.11 ETHERNET INTERFACE CONFIGURATION
Access the Ethernet Interface Configuration screen from the Device
Configuration Menu screen by using the arrow keys to highlight the
ETHERNET INTERFACE CONFIGURATION menu item and
pressing ENTER. The Ethernet Interface Configuration
screen displays.
Figure 5-17 Ethernet Interface Configuration Screen for the 2H28-08R
The following section briefly explains each field of the Ethernet Interface
Configuration screen:
Port Num (Read-only)
Identifies the port number.
Port Type (Read-only)
Displays the name of the interface in ports 1 through 8. “Unknown” will
be displayed for port 7 or 8 if a Fast Ethernet Module is not installed in
those ports.
