Using LANVIEW
2H28-08R SmartSwitch 2208 User’s Guide 4-3
RX
(Receive)
LED for
ports 1–6,
also ports
7 and 8,
with
optional
FE-100FX
or
FE-100F3 Off No link. No activity.
Port could be enabled
or disabled. Check connections if no
activity is seen when the port
is enabled.
Green Blinking. Port
disabled. Enable the port if a connection
is desired.
Solid. Indicates link. None.
Amber Flashing. Port
enabled, activity. None.
Red Solid. Diagnostic
failure. Contact the Cabletron
Systems Global Call Center.
TX
(Transmit)
LED for
ports 1–6,
also ports
7 and 8,
with
optional
FE-100FX
or
FE-100F3 Off Port enabled, and no
activity. Should flash
green every two
seconds indicating
BPDUs being sent if
STA is enabled and
there is a valid link. 1. Ensure that the STA is
enabled and that there is a
valid link.
2. Contact the Cabletron
Systems Global Call Center
if problem still exists.
Green Flashing. Indicates
activity. Rate indicates
data rate. None.
Amber Blinking. Port in
standby. Port may be
disabled due to
Spanning Tree. 1. Ensure that the port is not
disabled intentionally.
2. Contact the Cabletron
Systems Global Call Center
if problem still exists.
Red Flashing. Indicates
collision rate. No action, unless a high
amount of activity-check for
network configuration
problems or bad device.
Solid. Diagnostic
failure. Contact the Cabletron
Systems Global Call Center.
Table 4-1 LANVIEW LEDs (Continued)
LED Color State Recommended Action
