2H28-08R SmartSwitch 2208 User’s Guide 3-1
CHAPTER 3
INSTALLATION
This chapter provides the instructions to install the 2H28-08R. Follow the
order of the sections listed below to correctly install the 2H28-08R.
• Required Tools ( Section 3.1 )
• Unpacking the 2H28-08R ( Section 3.2 )
• Installing Optional Equipment ( Section 3.3 )
• Installing the 2H28-08R (on a shelf, tabletop, or into a standard rack)
(
Section 3.4 )
• Connecting to the Network ( Section 3.5 )
• Completing the Installation ( Section 3.6 )
3.1 REQUIRED TOOLS
A Phillips screwdriver is required to install the 2H28-08R in a rack, and to
install any optional Fast Ethernet Interface Modules.
3.2 UNPACKING THE 2H28-08R
To unpack the 2H28-08R and verify the contents of the shipment, proceed
as follows:
1. Open the carton and remove the packing material protecting the
2H28-08R.
2. Verify the contents of the carton as listed in Table 3-1 .
Only qualified personnel should install the 2H28-08R.
